The Trio is Peco InspX’s high performance rigid package X-ray inspection system, with impressive performance in glass-in-glass identification. The Trio offers very high speed (> 1,000 containers per minute) non-contact container inspection.
The Trio leverages three X-ray beams powered from a single X-ray tube to provide 3 individual “looks” at each container, which allows optimal detection of asymmetric pieces of foreign material such as glass shards.
Customers are encouraged to consult with a Peco InspX sales specialist to determine which machine is best suited for their glass application.
All subsystems have been designed with the maximum system availability, redundancy, and fault tolerance in mind
Fill Level Measurement
High precision fill-level and headspace monitoring
Real-Time Remote Support
Integrated wireless connectivity allows for secure remote support 24/7 globally. Peco InspX can resolve over 95% of customer issues with our powerful remote diagnostics software
Robust IT Security
Fully integrated end-to-end IT security offerings ensure your networks aren’t vulnerable and are defended from any outside threats. Optional IoT module allows for seamless SCADA integration
Advanced X-ray Tube/Detector Design
High contrast X-ray tube with independent power supply allows for lowest cost of ownership. Detector hardened against wear to maximize the component lifetime
High Reliability Non-Contact Inspection
Mounts over the top of the customer’s existing conveyor, eliminating conveyor transfers into the machine for inspection. This design minimizes risk against conveyor jams over transfer points
3 Beams Powered by a Single X-ray Tube
The Trio offers the power of 3 X-ray beams with the simplicity of a single X-ray tube. This design offers maximized performance with minimum cost of ownership
Small Line Footprint
The Trio is the smallest footprint dedicated glass X-ray inspection system available on the market today. The Trio requires less than 9 ft (3 m) of linear line space
Glass Food Containers
Glass Beverage Containers
Empty Glass Containers
High Speed Operations
Manufacturers can easily operate at speeds over 1000 containers per minute - Peco InspX offers inspection, checkweighing and fill monitoring capable to match such performance.
Peco InspX strives to deliver the very best service in the industry and the quality of our service is well recognized across our global customer base.
Our inspection and detection software is custom designed constantly enhanced for technical excellence at our R&D facility in Silicon Valley.
Made in America
All systems are manufactured in our newly expanded facility in Modesto, California.
X-ray Tube Configuration
Max Width: 9 in (229 mm)
Max Height: 12 in (300 mm)
Standard: IP 66/NEMA 4X
Optional: IP 69K, Passivation
Supported SCADA Systems
Supported Cloud Platforms
Standard: 304 Stainless Steel
